Select your device, enter your serial number, then choose your instruments or bundle.
Add additional instruments to any existing Moku:Go device.
Please contact us for assistance.
Add additional instruments to any existing Moku:Lab device.
Please contact us for assistance.
Add additional instruments to any existing Moku:Pro device.
Please contact us for assistance.
Add additional instruments to any existing Moku:Delta device.
Please contact us for assistance.
Leverage the versatility and performance of the Moku:Go Digital Filter Box to interactively design and generate a range of infinite impulse response filters. For maximum flexibility, select from lowpass, highpass, bandpass, and bandstop filter shapes with up to seven fully configurable filter types, including Butterworth, Chebyshev, and elliptic. Upload your own filter coefficients for a filter truly customized to your own needs.
Leverage the versatile Moku:Go FIR Filter Builder to design and implement lowpass, highpass, bandpass, and bandstop finite impulse response (FIR) filters with up to 14,819 coefficients. It’s easy to fine-tune the filter response in the frequency and time domains to complement your specific application. For maximum flexibility, select between four frequency response shapes, five common impulse responses, and up to eight window functions.
The Moku:Go Frequency Response Analyzer enables you to measure the frequency response of a system in both magnitude and phase using a swept sine output from 10 mHz to 20 MHz. With up to two inputs and outputs available for Moku:Go, it’s easy to enable differential or ratiometric measurements. Select up to 8192 points per sweep and configure settling and averaging times to balance total sweep duration and signal-to-noise ratio.
The Moku:Go Laser Lock Box enables you to lock a laser’s frequency to a reference cavity or atomic transition using high-performance modulation locking techniques. The Laser Lock Box includes a Lock Assist feature, enabling you to quickly lock to any zero crossing on the demodulated error signal.
The Moku:Go Lock-in Amplifier supports dual-phase demodulation (X/Y or R/θ) from DC to 30 MHz. It also features an integrated two-channel Oscilloscope and Data Logger, enabling you to observe signals at up to 125 MSa/s and log data at up to 1 MSa/s.
With the Moku:Go PID Controller, it’s easy to leverage up to two fully configurable PID controllers to simplify system feedback and stabilization. Deploy them in applications requiring both low and high feedback bandwidths, such as laser temperature and current stabilization. For maximum flexibility, you can also utilize the PID Controller as a lead-lag compensator by saturating the integral and differential controllers with independent gain settings.
The Moku:Go Phasemeter measures the phase, relative to a reference clock, of up to two input signals from 1 kHz to 30 MHz. Built on a digitally implemented, phase-locked loop architecture, it provides exceptional dynamic range, zero dead time, and measurement precision that exceeds the performance of conventional lock-in amplifiers and frequency counters.
Count events with a timing jitter of less than 50 ps RMS with the Moku:Go Time & Frequency Analyzer. Feed configurable event detectors into up to two ultra-precise interval analyzers to replace your frequency counter, event counter, photon counter, and more — all with one versatile instrument that offers real-time, on-device histograms and interval statistics.
Leverage the versatility and performance of the Moku:Lab Digital Filter Box to interactively design and generate a range of infinite impulse response filters. For maximum flexibility, select from lowpass, highpass, bandpass, and bandstop filter shapes with up to seven fully configurable filter types, including Butterworth, Chebyshev, and elliptic. Upload your own filter coefficients for a filter truly customized to your own needs.
Leverage the versatile Moku:Lab FIR Filter Builder to design and implement lowpass, highpass, bandpass, and bandstop finite impulse response (FIR) filters with up to 14,819 coefficients. It’s easy to fine-tune the filter response in the frequency and time domains to complement your specific application. For maximum flexibility, select between four frequency response shapes, five common impulse responses, and up to eight window functions.
The Moku:Lab Frequency Response Analyzer enables you to measure the frequency response of a system in both magnitude and phase using a swept sine output from 10 mHz to 200 MHz. With up to two inputs and outputs available for Moku:Lab, it’s easy to enable differential or ratiometric measurements. Select up to 8192 points per sweep and configure settling and averaging times to balance total sweep duration and signal-to-noise ratio.
The Moku:Lab Laser Lock Box enables you to lock a laser’s frequency to a reference cavity or atomic transition using high-performance modulation locking techniques. The Laser Lock Box includes a Lock Assist feature, enabling you to quickly lock to any zero crossing on the demodulated error signal. With Multi-Instrument Mode, you can deploy multiple laser lock modules simultaneously. Each module shares the same clock base from the internal or an external source. This is the ideal solution for multi-laser stabilization systems.
The Moku:Lab Lock-in Amplifier supports dual-phase demodulation (X/Y or R/θ) from DC to 200 MHz. It also features an integrated two-channel Oscilloscope and Data Logger, enabling you to observe signals at up to 500 MSa/s and log data at up to 250 kSa/s.
The Moku:Lab Logic Analyzer/Pattern Generator utilizes the devices’ analog input and output ports to stimulate, monitor, capture, and debug digital systems. Use the integrated Protocol Analyzer and Pattern Generator features to enable full digital circuit design and analysis, or debug custom designs quickly and efficiently in Multi-Instrument Mode.
With the Moku:Lab PID Controller, it’s easy to leverage two fully configurable PID controllers to simplify system feedback and stabilization. Deploy them in applications requiring both low and high feedback bandwidths, such as laser temperature and current stabilization. For maximum flexibility, you can also utilize the Moku PID Controller as a lead-lag compensator by saturating the integral and differential controllers with independent gain settings.
The Moku:Lab Phasemeter measures the phase, relative to a reference clock, of up to two input signals with better than 6 μradian precision from 1 kHz to 200 MHz. Built on a digitally implemented, phase-locked loop architecture, it provides exceptional dynamic range, zero dead time, and measurement precision that exceeds the performance of conventional lock-in amplifiers and frequency counters.
Count events with a timing jitter of less than 20 ps RMS with the Moku:Lab Time & Frequency Analyzer. Feed configurable event detectors into up to four ultra-precise interval analyzers to replace your frequency counter, event counter, photon counter, and more — all with one versatile instrument that offers real-time, on-device histograms and interval statistics.
Leverage the versatility and performance of the Moku:Delta Digital Filter Box to interactively design and generate a range of infinite impulse response filters. For maximum flexibility, select from lowpass, highpass, bandpass, and bandstop filter shapes with fully configurable filter types, including Butterworth, Chebyshev, and elliptic. Upload your own filter coefficients for a filter truly customized to your own needs.
Leverage the versatile Moku:Pro FIR Filter Builder to design and implement lowpass, highpass, bandpass, and bandstop finite impulse response (FIR) filters with up to 14,819 coefficients. It’s easy to fine-tune the filter response in the frequency and time domains to complement your specific application. For maximum flexibility, select between four frequency response shapes, five common impulse responses, and up to eight window functions.
The Moku:Delta Frequency Response Analyzer enables you to measure the frequency response of a system in both magnitude and phase using a swept sine output from 10 mHz to 2 GHz. With up to eight inputs and outputs available for Moku:Pro, it’s easy to enable differential or ratiometric measurements. Select up to 8192 points per sweep and configure settling and averaging times to balance total sweep duration and signal-to-noise ratio.
The Moku:Pro Laser Lock Box enables you to lock a laser’s frequency to a reference cavity or atomic transition using high-performance modulation locking techniques. The Laser Lock Box includes a Lock Assist feature, enabling you to quickly lock to any zero crossing on the demodulated error signal. With Multi-Instrument Mode, you can deploy multiple laser lock modules simultaneously. Each module shares the same clock base from the internal or an external source. This is the ideal solution for multi-laser stabilization systems.
The Moku:Delta Lock-in Amplifier supports dual-phase demodulation (X/Y or R/θ) from DC to 2 GHz. It also features an integrated four-channel Oscilloscope and Data Logger, enabling you to observe signals at up to 5 GSa/s and log data at up to 10 MSa/s.
The Moku:Pro Logic Analyzer/Pattern Generator utilizes the devices’ analog input and output ports to stimulate, monitor, capture, and debug digital systems. Use the integrated Protocol Analyzer and Pattern Generator features to enable full digital circuit design and analysis, or debug custom designs quickly and efficiently in Multi-Instrument Mode.
With the Moku:Pro PID Controller, it’s easy to leverage up to four fully configurable PID controllers to simplify system feedback and stabilization. Deploy them in applications requiring both low and high feedback bandwidths, such as laser temperature and current stabilization. For maximum flexibility, you can also utilize the Moku PID Controller as a lead-lag compensator by saturating the integral and differential controllers with independent gain settings.
The Moku:Pro Phasemeter measures the phase, relative to a reference clock, of up to four input signals with better than 6 μradian precision from 1 kHz to 300 MHz. Built on a digitally implemented, phase-locked loop architecture, it provides exceptional dynamic range, zero dead time, and measurement precision that exceeds the performance of conventional lock-in amplifiers and frequency counters.
Count events with a timing jitter of less than 20 ps RMS with the Moku:Pro Time & Frequency Analyzer. Feed configurable event detectors into up to four ultra-precise interval analyzers to replace your frequency counter, event counter, photon counter, and more — all with one versatile instrument that offers real-time, on-device histograms and interval statistics.
Test equipment you can customize. Run custom DSP or your own unique instruments using Moku hardware, no complex design required.
Interactively design and generate a range of infinite impulse response (IIR) filters. Select from lowpass, highpass, bandpass, and bandstop filter shapes with up to eight fully configurable filter types, including Butterworth, Chebyshev, and elliptic.
Leverage the versatile Moku:Delta FIR Filter Builder to design and implement lowpass, highpass, bandpass, and bandstop finite impulse response (FIR) filters with up to 14,819 coefficients. It’s easy to fine-tune the filter response in the frequency and time domains to complement your specific application. For maximum flexibility, select between four frequency response shapes, five common impulse responses, and up to eight window functions.
Perform multi-channel Bode analysis with up to eight inputs and outputs, including differential or ratiometric measurements. Quickly measure the frequency response or transfer function of a device under test with industry-leading noise performance and bandwidth.
Bidirectional, high-speed data streaming. Transfer data over the 100 GbE QSFP interface at up to 80 Gbps and the dual 10 GbE SFP interfaces at up to 5 Gbps.
Bidirectional, high-speed data streaming. Transfer data over the 100 GbE QSFP interface at up to 80 Gbps and the dual 10 GbE SFP interfaces at up to 5 Gbps.
The Moku:Delta Laser Lock Box enables you to lock a laser’s frequency to a reference cavity or atomic transition using high-performance modulation locking techniques. The Laser Lock Box includes a Lock Assist feature, enabling you to quickly lock to any zero crossing on the demodulated error signal. With Multi-Instrument Mode, you can deploy multiple laser lock modules simultaneously. Each module shares the same clock base from the internal or an external source. This is the ideal solution for multi-laser stabilization systems.
Perform dual-phase demodulation up to 2 GHz with an excellent dynamic reserve. With an easy-to-use interface, and a leading cost-per-channel in all classes, the Moku Lock-in Amplifier adapts to the evolving demands of cutting-edge scientific experiments.
With the Moku:Delta PID Controller, it’s easy to leverage up to eight fully configurable PID controllers to simplify system feedback and stabilization. Deploy them in applications requiring both low and high feedback bandwidths, such as laser temperature and current stabilization. For maximum flexibility, you can also utilize the Moku PID Controller as a lead-lag compensator by saturating the integral and differential controllers with independent gain settings.
The Moku:Delta Phasemeter measures the phase, relative to a reference clock, of up to eight input signals from 1 kHz to 2 GHz. Built on a digitally implemented, phase-locked loop architecture, it provides exceptional dynamic range, zero dead time, and measurement precision that exceeds the performance of conventional lock-in amplifiers and frequency counters.
Count events with a digital resolution of 0.2 ps with the Moku:Delta Time & Frequency Analyzer. Feed configurable event detectors into up to eight ultra-precise interval analyzers to replace your frequency counter, event counter, photon counter, and more — all with one versatile instrument that offers real-time, on-device histograms and interval statistics.
Test equipment you can customize. Run custom DSP or your own unique instruments using Moku hardware, no complex design required.
Contact sales to upgrade your Moku:Go
Contact sales to upgrade your Moku:Lab
Contact sales to upgrade your Moku:Pro
Contact sales to upgrade your Moku:Delta
