Data Logger
Data Logger
Engineered for flexibility, the Moku Data Logger lets you log data directly to an SD card, a networked disk, or internal memory with sampling rates of up to 10 MSa/s. On Moku:Pro, input noise is measured at 30 nV/√Hz at 100 Hz with our blended ADC technology, providing ultra-low-noise data logging from acoustic to RF frequencies. Moku:Pro and Moku:Lab are equipped with 10 MHz clock synchronization I/O, allowing flexible integration with other electronics.
- Available on
- Moku:Pro >
- Moku:Lab >
- Moku:Go >
The Moku Data Logger is easy to use and offers a range of advanced capabilities to optimize your experiment — at the most cost-effective price in the industry.
Key benefits of the Moku Data Logger
With up to four independent channels, a maximum acquisition rate up to 10 MSa/s, and an optional precision acquisition mode, you can expect more from the Moku Data Logger.
Flexible export options with the versatile Moku Data Logger
It’s easy to log critical voltage data on each independent input channel. Log to internal memory, a solid-state drive, or an SD card depending on your hardware platform. Once you’re done, export data directly to your computer or cloud-based storage.
Try the software
Drive your signal and log the output
With the embedded Waveform Generator, choose from five prebuilt waveforms and generate on up to four output channels, all within the Data Logger instrument.
Set it and forget it with advanced scheduling and triggered start
Schedule a log to start after a delay of up to 10 days, or set up a trigger event to start your logging session. Make long-term measurements limited only by the internal storage of the device or the size of your SD card.
Export your data how you want it, where you want it
Easily export data to an SD card, Dropbox, email, iCloud, or the iPad “My Files” folder. Log data to binary files and convert to plain text (CSV) or MATLAB (.MAT) files using the LI file converter.
Engineered to work seamlessly with your preferred APIs
API integration with Python, MATLAB, and LabVIEW allows straightforward automation of your Moku device in complex setups or for repetitive tasks. Save your measurements, screenshots, traces, and other settings locally or to your preferred cloud app. You can also send work to yourself or colleagues within the Moku app.
Engineered for demanding applications
Use the Moku Data Logger to accelerate development timelines with speed and flexibility unmatched by any other instrument in its class.
Embedded instrument data logging
Environmental monitoring
Sensor data recording
Temperature monitoring
Vibration analysis
Integrates seamlessly with your tech stack
Specifications and technical documents
The Moku Data Logger runs on Moku:Pro, Moku:Lab, and Moku:Go. Compare the specifications to choose the right device for your application.
Technical specifications
Channels
4
2
2
Acquisition rate
10 MSa/s with one channel enabled
5 MSa/s with two channels enabled
2.5 MSa/s with four channels enabled
250 kSa/s with one channel enabled
125 kSa/s with both channels enabled
1 MSa/s with one channel enabled
500 kSa/s with both channels enabled
Input range
-20 V to 20 V
-5 V to 5 V
± 5 V to ± 25 V
Input impedance
50 Ω/1 MΩ
50 Ω/1 MΩ
1 MΩ
Logging options
Solid-state drive (240 GB)
API data streaming
SD card
API data streaming
Internal memory (8 GB)
API data streaming
Software & utilities
Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW
Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW
Windows, macOS, iPadOS, and visionOS apps
API support for Python, MATLAB, and LabVIEW
Documentation
Datasheets
User manuals
Specs
Moku:Pro
Data Logger
Technical specifications
Channels
4
Acquisition rate
10 MSa/s with one channel enabled
5 MSa/s with two channels enabled
2.5 MSa/s with four channels enabled
Input range
-20 V to 20 V
Input impedance
50 Ω/1 MΩ
Logging options
Solid-state drive (240 GB)
API data streaming
Software & utilities
iPadOS app
macOS app, Windows app
API support for Python, MATLAB, and LabVIEW
Documentation
Datasheets
User manuals
Specs
Moku:Lab
Data Logger
Technical specifications
Channels
2
Acquisition rate
250 kSa/s with one channel enabled
125 kSa/s with both channels enabled
Input range
-5 V to 5 V
Input impedance
50 Ω/1 MΩ
Logging options
SD card
API data streaming
Software & utilities
iPadOS app
macOS app, Windows app
API support for Python, MATLAB, and LabVIEW
Documentation
Datasheets
User manuals
Specs
Moku:Go
Data Logger
Technical specifications
Channels
2
Acquisition rate
1 MSa/s with one channel enabled
500 kSa/s with both channels enabled
Input range
± 5 V to ± 25 V
Input impedance
1 MΩ
Logging options
Internal memory (8 GB)
API data streaming
Software & utilities
macOS app, Windows app
API support for Python, MATLAB, and LabVIEW
Documentation
Datasheets
User manuals
Specs
Featured resources
From detailed case studies featuring real-world users to comprehensive application notes that explore instrument features and functions, we offer a range of resources to help you work smarter and achieve more with the Moku Data Logger.
